Anti-Tau Antibody (pThr217) [15B7]

Mouse Anti-Human Tau (pThr217) Monoclonal IgG1 Kappa

Catalog No. SMC-615

0 out of 5 based on 0 customer ratings
Reviews (0) | Datasheet
Species Reactivity Hu, Ms, Rt
Applications WB IHC ICC/IF FCM IP
SKU: SMC-615 Categories: ,

Clear
+ Compare Bulk Quote
Mouse Anti-Tau Antibody (pThr217) [15B7] used in Dot Blot (DB) on Human, Mouse, Rat Tau 2N4R P301S (phospho & non-phospho) (SMC-615)Mouse Anti-Tau Antibody (pThr217) [15B7] used in Western Blot (WB) on Human, Mouse, Rat baculovirus expressed hTau 2N4R monomer (SMC-615)
Product Name Tau Antibody (pThr217)
Description

Mouse Anti-Human Tau (pThr217) Monoclonal IgG1 Kappa
Species Reactivity Human, Mouse, Rat
Applications WB, DB
Antibody Dilution WB (1:1000); optimal dilutions for assays should be determined by the user.
Host Species Mouse
Immunogen Species Human
Immunogen Synthetic peptide of Wild-type Human Tau (pThr217) AA 210-224: SRTPSLP-pT-PPTREPK
Concentration 1mg/mL
Conjugates APC, ATTO 390, ATTO 488, ATTO 594, Biotin, FITC, HRP, PerCP, RPE, Unconjugated
Dylight 488
Overview:

  • High fluorescence yield
  • High photostability
  • Less pH-sensitive
  • Excellent batch-to-batch reproducibility
  • Stringently QC tested
  • Molecular weight: 1011 g/mol

Dylight 488 Datasheet

 Dylight 488 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 493 nm

λem = 518 nm

εmax = 7.0×104

Laser = 488 nm



APC/Cy7
Overview:

  • High quantum yield
  • Excellent batch-to-batch reproducibility
  • Stringently QC tested

APC-Cy7 Datasheet



 ACP-Cy7 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 652 nm

λem = 790 nm

Laser = 594 or 633 nm





  Dylight 350
Overview:

  • High fluorescence intensity
  • High photostability
  • Less pH-sensitive
  • Excellent solubility in water
  • Stringently QC tested
  • Excellent batch-to-batch reproducibility
  • Molecular weight: 874 g/mol

Dylight 350 Datasheet

 Dylight 350 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 353 nm

λem = 432 nm

εmax = 1.5×104





  Dylight 405
Overview:

  • High fluorescence intensity
  • High photostability
  • Less pH-sensitive
  • Excellent batch-to-batch reproducibility
  • Stringently QC tested
  • Molecular weight: 793 g/mol

Dylight 405 Datasheet

 Dylight 405 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 400 nm

λem = 420 nm

εmax = 3.0×104

Laser = 405 nm



Dylight 594
Overview:

  • High fluorescence yield
  • High photostability
  • Less pH-sensitive
  • Excellent batch-to-batch reproducibility
  • Stringently QC tested
  • Molecular weight: 1078 g/mol

Dylight 594 Datasheet

 Dylight 594 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 593 nm

λem = 618 nm

εmax = 8.0×104

Laser = 526 nm



 Dylight 633
Overview:

  • High fluorescence yield
  • High photostability
  • Less pH-sensitive
  • Excellent batch-to-batch reproducibility
  • Stringently QC tested
  • Molecular weight: 1066 g/mol

Dylight 633 Datasheet

 Dylight 633 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 638 nm

λem = 658 nm

εmax = 1.7×105

Laser = 633 nm



 PerCP
Overview:

  • Peridinin-Chlorophyll-Protein Complex
  • Small phycobiliprotein
  • Isolated from red algae
  • Large stokes shift (195 nm)
  • Molecular Weight: 35 kDa

PerCP Datasheet

  PerCP Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 482 nm

λem = 677 nm

εmax = 1.96 x 106

Laser = 488 nm



 PE/ATTO 594
PE/ATTO 594 is a tandem conjugate, where PE is excited at 535 nm and transfers energy to ATTO 594 via FRET (fluorescence resonance energy transfer), which emits at 627 nm.
Overview:

  • High fluorescence yield
  • High photostability
  • Very hydrophilic
  • Excellent solubility in water
  • Very little aggregation

PE/ATTO 594 Datasheet

 PE-ATTO 594 Fluorophore Conjugate Excitation and Emission Spectra Optical Properties:

λex = 535 nm

λem = 627 nm

Laser = 488 to 561 nm



  FITC (Fluorescein)
Overview:

  • Excellent fluorescence quantum yield
  • High rate of photobleaching
  • Good solubility in water
  • Broad emission spectrum
  • pH dependent spectra
  • Molecular formula: C20H12O5
  • Molar mass: 332.3 g/mol

FITC-Fluorescent-conjugate

 FITC Fluorescein Fluorophore Excitation and Emission Spectra Optical Properties:

λex = 494 nm

λem = 520 nm

εmax = 7.3×104

Φf = 0.92

τfl = 5.0 ns

Brightness = 67.2

Laser = 488 nm

Filter set = FITC



 ATTO 700
Overview:

  • High fluorescence yield
  • Excellent thermal and photostability
  • Quenched by electron donors
  • Very hydrophilic
  • Good solubility in polar solvents
  • Zwitterionic dye
  • Molar Mass: 575 g/mol

ATTO 700 Datasheet

  ATTO 700 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 700 nm

λem = 719 nm

εmax = 1.25×105

Φf = 0.25

τfl = 1.6 ns

Brightness = 31.3

Laser = 676 nm

Filter set = Cy®5.5



 ATTO 680
Overview:

  • High fluorescence yield
  • Excellent thermal and photostability
  • Quenched by electron donors
  • Very hydrophilic
  • Good solubility in polar solvents
  • Zwitterionic dye
  • Molar Mass: 631 g/mol

ATTO 680 Datasheet

  ATTO 680 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 680 nm

λem = 700 nm

εmax = 1.25×105

Φf = 0.30

τfl = 1.7 ns

Brightness = 37.5

Laser = 633 – 676 nm

Filter set = Cy®5.5



 ATTO 655
Overview:

  • High fluorescence yield
  • High thermal and photostability
  • Excellent ozone resistance
  • Quenched by electron donors
  • Very hydrophilic
  • Good solubility in polar solvents
  • Zwitterionic dye
  • Molar Mass: 634 g/mol

ATTO 655 Datasheet

 ATTO 655 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 663 nm

λem = 684 nm

εmax = 1.25×105

Φf = 0.30

τfl = 1.8 ns

Brightness = 37.5

Laser = 633 – 647 nm

Filter set = Cy®5



 ATTO 633
Overview:

  • High fluorescence yield
  • High thermal and photostability
  • Moderately hydrophilic
  • Good solubility in polar solvents
  • Stable at pH 4 – 11
  • Cationic dye, perchlorate salt
  • Molar Mass: 652.2 g/mol

ATTO 633 Datasheet

 ATTO 633 Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 629 nm

λem = 657 nm

εmax = 1.3×105

Φf = 0.64

τfl = 3.2 ns

Brightness = 83.2

Laser = 633 nm

Filter set = Cy®5



 ATTO 594
Overview:

  • High fluorescence yield
  • High photostability
  • Very hydrophilic
  • Excellent solubility in water
  • Very little aggregation
  • New dye with net charge of -1
  • Molar Mass: 1137 g/mol

ATTO 594 Datasheet

  ATTO 594 Fluorophore Excitation and Emission Spectrum Optical Properties:

λex = 601 nm

λem = 627 nm

εmax = 1.2×105

Φf = 0.85

τfl = 3.5 ns

Brightness = 102

Laser = 594 nm

Filter set = Texas Red®



 ATTO 565
Overview:

  • High fluorescence yield
  • High thermal and photostability
  • Good solubility in polar solvents
  • Excellent solubility in water
  • Very little aggregation
  • Rhodamine dye derivative
  • Molar Mass: 611 g/mol

ATTO 565 Datasheet

  ATTO 565 Fluorophore Excitation and Emission Spectra Optical Properties:

λex = 563 nm

λem = 592 nm

εmax = 1.2×105

Φf = 0.9

τfl = 3.4 n

Brightness = 10

Laser = 532 nm

Filter set = TRITC



  ATTO 488
Overview:

  • High fluorescence yield
  • High photostability
  • Very hydrophilic
  • Excellent solubility in water
  • Very little aggregation
  • New dye with net charge of -1
  • Molar Mass: 804 g/mol

ATTO 488 Datasheet

   ATTO 488 Fluorophore Excitation and Emission Spectra Optical Properties:

λex = 501 nm

λem = 523 nm

εmax = 9.0×104

Φf = 0.80

τfl = 4.1 ns

Brightness = 72

Laser = 488 nm

Filter set = FITC



  ATTO 390
Overview:

  • High fluorescence yield
  • Large Stokes-shift (89 nm)
  • Good photostability
  • Moderately hydrophilic
  • Good solubility in polar solvents
  • Coumarin derivate, uncharged
  • Low molar mass: 343.42 g/mol

ATTO 390 Datasheet

 ATTO 390 Fluorescent Dye Excitation and Emission Spectra Optical Properties:

λex = 390 nm

λem = 479 nm

εmax = 2.4×104

Φf = 0.90

τfl = 5.0 ns

Brightness = 21.6

Laser = 365 or 405 nm



APC (Allophycocyanin)
Overview:

  • High quantum yield
  • Large phycobiliprotein
  • 6 chromophores per molecule
  • Isolated from red algae
  • Molecular Weight: 105 kDa

APC Datasheet

  APC Fluorophore Absorption and Emission Spectrum Optical Properties:

λex = 650 nm

λem = 660 nm

εmax = 7.0×105

Φf = 0.68

Brightness = 476

Laser = 594 or 633 nm

Filter set = Cy®5



Streptavidin

Properties:

  • Homo-tetrameric protein purified from Streptomyces avidinii which binds four biotin molecules with extremely high affinity
  • Molecular weight: 53 kDa
  • Formula: C10H16N2O3S
  • Applications: Western blot, immunohistochemistry, and ELISA

Streptavidin Datasheet

BiotinBiotin Conjugate Structure

Properties:

  • Binds tetrameric avidin proteins including Streptavidin and neuravidin with very high affinity
  • Molar mass: 244.31 g/mol
  • Formula: C10H16N2O3S
  • Applications: Western blot, immunohistochemistry, and ELISA

Biotin Datasheet

HRP (Horseradish peroxidase)

Properties:

  • Enzymatic activity is used to amplify weak signals and increase visibility of a target
  • Readily combines with hydrogen peroxide (H2O2) to form HRP-H2O2 complex which can oxidize various hydrogen donors
  • Catalyzes the conversion of:
    • Chromogenic substrates (e.g. TMB, DAB, ABTS) into coloured products
    • Chemiluminescent substrates (e.g. luminol and isoluminol) into light emitting products via enhanced chemiluminescence (ECL)
    • Fluorogenic substrates (e.g. tyramine, homovanillic acid, and 4-hydroxyphenyl acetic acid) into fluorescent products
  • High turnover rate enables rapid generation of a strong signal
  • 44 kDa glycoprotein
  • Extinction coefficient: 100 (403 nm)
  • Applications: Western blot, immunohistochemistry, and ELISA

HRP Datasheet

AP (Alkaline Phosphatase)

Properties:

  • Broad enzymatic activity for phosphate esters of alcohols, amines, pyrophosphate, and phenols
  • Commonly used to dephosphorylate the 5’-termini of DNA and RNA to prevent self-ligation
  • Catalyzes the conversion of:
    • Chromogenic substrates (e.g. pNPP, naphthol AS-TR phosphate, BCIP) into coloured products
    • Fluorogenic substrates (e.g. 4-methylumbelliferyl phosphate) into fluorescent products
  • Molecular weight: 140 kDa
  • Applications: Western blot, immunohistochemistry, and ELISA

AP Datasheet

  R-PE (R-Phycoerythrin)
Overview:

  • Broad excitation spectrum
  • High quantum yield
  • Photostable
  • Member of the phycobiliprotein family
  • Isolated from red algae
  • Excellent solubility in water
  • Molecular Weight: 250 kDa

R-PE Datasheet

  R-PE Fluorophore Excitation and Emission Spectra Optical Properties:

λex = 565 nm

λem = 575 nm

εmax = 2.0×106

Φf = 0.84

Brightness = 1.68 x 103

Laser = 488 to 561 nm

Filter set = TRITC


Field of Use Not for use in humans. Not for use in diagnostics or therapeutics. For in vitro research use only.

Properties

Storage Buffer PBS pH 7.4, 50% glycerol, 0.09% Sodium azide *Storage buffer may change when conjugated
Storage Temperature -20ºC, Conjugated antibodies should be stored according to the product label
Shipping Temperature Blue Ice or 4ºC
Purification Protein G Purified
Clonality Monoclonal
Clone Number 15B7
Isotype IgG1 Kappa
Specificity Detects phosphorylation on Thr217
Cite This Product Mouse Anti-Human Tau Antibody (pThr217) Monoclonal (StressMarq Biosciences, Victoria BC, Cat# SMC-615)
Certificate of Analysis A 1:1000 dilution of SMC-615 was sufficient for detection of Tau in 10 µg of Human, Mouse, Rat Tau Peptide (pThr217) by DB analysis using Goat Anti-Mouse IgG:HRP as the secondary antibody.

Biological Description

Alternative Names Microtubule associated protein tau | phospho tau
Research Areas Alzheimer's Disease, Axon Markers, Cell Markers, Cell Signaling, Cytoskeleton, Microtubules, MT Associated Proteins, Neurodegeneration, Neuron Markers, Neuroscience, Tangles & Tau
Cellular Localization Intracellular, Secreted
Accession Number NP_058519.3
Gene ID 4137
Swiss Prot P10636
Scientific Background This gene encodes the microtubule-associated protein tau (MAPT) whose transcript undergoes complex, regulated alternative splicing, giving rise to several mRNA species. MAPT transcripts are differentially expressed in the nervous system, depending on stage of neuronal maturation and neuron type.

Product Images

<p>Dot Blot analysis of Tau Peptide (pThr217) showing detection of Tau protein using Mouse Anti-Tau Monoclonal Antibody, Clone 15B7 (SMC-615). Panel A: hTau 2N4R monomer (pSer214) (2 ug). Panel B: Tau peptide (pThr217) (2 ug). Panel C: Tau peptide (non phospho) (2 ug). Panels on the right are negative control with secondary antibody only. Load: 2ug. Block: 5% Skim Milk in 1X TBST. Primary Antibody: Mouse Anti-Tau Monoclonal Antibody (SMC-615) at 1:1000 for 1 hour at RT with shaking. Secondary Antibody: Goat anti-mouse IgG:HRP at 1:4000 for 1/2 hour at RT with shaking. Color Development: Chemiluminescent for HRP (Moss) for 1 min in ECL. Phospho peptide sequence: SRTPSLP-pT-PPTREPK. Non-phospho peptide sequence: SRTPSLPTPPTREPK. This sequence is the same for human, mouse, and rat.</p>

Dot Blot analysis of Tau Peptide (pThr217) showing detection of Tau protein using Mouse Anti-Tau Monoclonal Antibody, Clone 15B7 (SMC-615). Panel A: hTau 2N4R monomer (pSer214) (2 ug). Panel B: Tau peptide (pThr217) (2 ug). Panel C: Tau peptide (non phospho) (2 ug). Panels on the right are negative control with secondary antibody only. Load: 2ug. Block: 5% Skim Milk in 1X TBST. Primary Antibody: Mouse Anti-Tau Monoclonal Antibody (SMC-615) at 1:1000 for 1 hour at RT with shaking. Secondary Antibody: Goat anti-mouse IgG:HRP at 1:4000 for 1/2 hour at RT with shaking. Color Development: Chemiluminescent for HRP (Moss) for 1 min in ECL. Phospho peptide sequence: SRTPSLP-pT-PPTREPK. Non-phospho peptide sequence: SRTPSLPTPPTREPK. This sequence is the same for human, mouse, and rat.

<p>Dot Blot analysis of Tau 2N4R P301S (phospho & non-phospho) showing detection of Tau protein using Mouse Anti-Tau Monoclonal Antibody, Clone 15B7 (SMC-615). Lane 1: hTau 2N4R P301S Monomer(0.5ug). Lane 2: hTau 2N4R P301S Monomer(1.0ug). Lane 3: Recombinant hTau-441 (2N4R) P301S Monomer, Baculovirus/Sf9 Expressed (phosphorylated)(0.5ug). Lane 4: Recombinant hTau-441 (2N4R) P301S Monomer, Baculovirus/Sf9 Expressed (phosphorylated)(1.0ug). Load: 0.5ug, 1.0ug. Block: 5% BSA in TBST. Primary Antibody: Mouse Anti-Tau Monoclonal Antibody (SMC-615) at 1:4 for Overnight, 4C, with shaking. Secondary Antibody: Goat anti-mouse IgG:HRP at 1:4000 for 1 hour at RT with shaking. Color Development: Chemiluminescent for HRP (Moss) for 5 min in RT. Dot Blot performed with supernatants.</p>

Dot Blot analysis of Tau 2N4R P301S (phospho & non-phospho) showing detection of Tau protein using Mouse Anti-Tau Monoclonal Antibody, Clone 15B7 (SMC-615). Lane 1: hTau 2N4R P301S Monomer(0.5ug). Lane 2: hTau 2N4R P301S Monomer(1.0ug). Lane 3: Recombinant hTau-441 (2N4R) P301S Monomer, Baculovirus/Sf9 Expressed (phosphorylated)(0.5ug). Lane 4: Recombinant hTau-441 (2N4R) P301S Monomer, Baculovirus/Sf9 Expressed (phosphorylated)(1.0ug). Load: 0.5ug, 1.0ug. Block: 5% BSA in TBST. Primary Antibody: Mouse Anti-Tau Monoclonal Antibody (SMC-615) at 1:4 for Overnight, 4C, with shaking. Secondary Antibody: Goat anti-mouse IgG:HRP at 1:4000 for 1 hour at RT with shaking. Color Development: Chemiluminescent for HRP (Moss) for 5 min in RT. Dot Blot performed with supernatants.

<p>Western Blot analysis of baculovirus-expressed human Tau 2N4R monomer showing detection of Tau protein phosphorylated at Thr217 using Mouse Anti-Tau Monoclonal Antibody, Clone 15B7 (SMC-615). Lane 1: Biorad All Blue Standards (3uL), Lane 2: baculovirus expressed hTau 2N4R monomer (2ug), lane 3: baculovirus expressed hTau 2N4R monomer (4ug). Block: 5% Skim Milk in TBST, 1/2 hr at RT with shaking. Primary Antibody: Mouse Anti-Tau Monoclonal Antibody (SMC-615) at 1:1000 for 1 hour at RT. Secondary Antibody: Goat anti-mouse IgG:HRP at 1:4000 for 1/2 hour at RT with shaking. Color Development: Chemiluminescent for HRP (Moss) for 1 min in RT. Species reactivity with Mouse & Rat. Baculovirus-expressed hTau 2N4R wildtype monomer purified in-house.</p>

Western Blot analysis of baculovirus-expressed human Tau 2N4R monomer showing detection of Tau protein phosphorylated at Thr217 using Mouse Anti-Tau Monoclonal Antibody, Clone 15B7 (SMC-615). Lane 1: Biorad All Blue Standards (3uL), Lane 2: baculovirus expressed hTau 2N4R monomer (2ug), lane 3: baculovirus expressed hTau 2N4R monomer (4ug). Block: 5% Skim Milk in TBST, 1/2 hr at RT with shaking. Primary Antibody: Mouse Anti-Tau Monoclonal Antibody (SMC-615) at 1:1000 for 1 hour at RT. Secondary Antibody: Goat anti-mouse IgG:HRP at 1:4000 for 1/2 hour at RT with shaking. Color Development: Chemiluminescent for HRP (Moss) for 1 min in RT. Species reactivity with Mouse & Rat. Baculovirus-expressed hTau 2N4R wildtype monomer purified in-house.

Reviews

Reviews

There are no reviews yet.

Be the first to review “Tau Antibody (pThr217)”

Your email address will not be published. Required fields are marked *
